HELIX 7 G2N SI
HELIX 7 G2N CHIRP SI GPS
CHIRP Side Imaging Sonar GPS with Networking
HELIX 7 CHIRP SI GPS G2N | HELIX 7 Series | 410340-1
The HELIX 7 CHIRP SI GPS G2N features a large 7" display with LED backlight, CHIRP-ing Side Imaging, Down Imaging and 2D sonar. Includes GPS chartplotting, built-in Bluetooth, Ethernet networking capabilities, AutoChart Live with depth, vegetation and bottom hardness mapping.
*Optional 50 kHz transducers available for extreme deepwater.
BROADBAND CHIRP SONAR
View low, mid and high Chirp ranges, either individually or all at once.
DOWN IMAGING SONAR
Get a fish-eye's view of what's happening below your boat. Incredible images are created with High-frequency sound waves.
Boat performance, weather or water conditions, make sense of it all with our networking solutions.
NMEA 2000 (OPTIONAL)
Get an at-a-glance view of fuel consumption, engine performance and other vessel data.
360 IMAGING (OPTIONAL)
We have you surrounded. 360 Imaging allows you to isolate your sweep, see 5 preset views or see all around you.
HIGH DEFINITION DISPLAY
Provides bright, crystal-clear images for easy viewing in harsh sunlight.
I-PILOT LINK (OPTIONAL)
i-Pilot Link is an integrated GPS Trolling System available on select Minn Kota Ulterra, Terrova and PowerDrive V2 motors which enable your motor and Humminbird to communicate.
GPS antenna built into the head unit.
The Humminbird UniMap is a built-in map covering the contiguous US coastline, inland lakes and rivers at 30 meters per pixel resolution.
SmartStrike takes you straight to the action by showing you where the fish are biting at any given moment.
SIDE IMAGING SONAR
Gain a 180° side to side perspective on the world below the surface.
SINGLE CARD SLOT
Use for advanced cartography or to save your screenshots, sonar recordings and waypoints.
DUALBEAM PLUS SONAR
Two beams combine for great detail and a wide coverage area. Use the narrow beam for high-accuracy returns and bottom. Use the wide beam when you want a larger search area.
Rig up the ultimate fishing system. Use our 5-Port Ethernet switch to link together multiple Humminbird head units or share transducers.
Take command of how your sonar returns appear with our Clear and Max Modes.
Access software updates to enhance the performance of your Humminbird unit through their My Humminbird section of their website.
Make a map where there is no map. Our patent pending AutoChart Live allows you to create digital, detailed maps live and on the water. You can also use it to enhance your existing charts.
Take wireless control of your Humminbird with our new Bluetooth Remote and Dongle.
Surf the web, monitor weather and stay connected from the dock, offshore waters and in between.
MICRO SD CARD READER
Use for advanced cartography or to save screenshots, sonar recordings and waypoints or to update your units software.
Display Size - Diagonal: 7"
Display Pixel Matrix: 800H X 480V
Display Type: Color TFT
Display Colors Grayscale: 16-bit
Sonar Standard: CHIRP/Side Imaging/Down Imaging/DualBeam PLUS
Standard Sonar Coverage: 20°, 60° & (2) 85° @ -10db (Total of 180°)
Standard Sonar Frequency: 200/83/455 kHz
Sonar Optional: 50/455 kHz
Target Separation: 2.5"
Power Output RMS: 500 Watts
Power Output Peak to Peak: 4000 Watts
Depth Capability: 1500 ft
Temperature: Built-In Transducer
Speed: GPS Speed Included
Unit Size - Gimbal Mount: 10.54"W x 5.44"H x 1.13"D
Mount A Type: Gimbal Mount
Unit Size - Indash Mount: 10.54"W x 5.80"H x 3.68"D
Mount B Unit Size 2: Optional In-Dash
Mounting Options: Gimbal or Optional In-Dash
Transducer Standard: XNT 9 SI 180 T
Transducer Mounting: Transom
Power Input: 10.8-20 VDC
Power Draw: 900 mA
GPS Receiver: Included
GPS Tracking: Included
GPS Chartplotting: Included
Waypoints, Routes, Tracks/Points: 2,500, 50, 50/20,000
Humminbird Mapping: Optional
Navionics Platinum+: Optional
Platinum Capable: Optional
360 Imaging: Optional
i-Pilot Link: Optional
HD Radar: Optional
NMEA 2000: Optional
5 Port Expansion Module: Optional
Precision GPS: Included
Heading Sensor GPS: Optional
PC Connect: Optional
External GPS Receiver: Not Supported
AIS Compatability: Optional
SwitchFire Sonar: Included
Screen Snap Shot: Included
Sonar Recording: Included
Humminbird PC: Included
Upgradable Internal Software: Included
Split Screen Zoom: Included
Split Screen Bottom Lock: Included
3D Chart View: Included
Large Digits View: Included
Wide/Narrow Cone Split Screen: Included
Custom View Selections: Included
Custom Digital Readout: Included
View Preset Keys: Not Supported
Temperature Graph: Not Supported
Temperature Alarm: Included
Freeze Frame: Included
Instant Image Update: Included
Mark Structure on Sonar: Included
Selective Fish ID+: Included
Real Time Sonar: Included
X-Press Menu System: Included
Card Reader Available: Yes
# Card Slots: 1
