HELIX 12 G2N DI
HELIX 12 CHIRP DI GPS G2N
Internal GPS Combo - Down Imaging
The HELIX 12 CHIRP DI GPS G2N features a large 12.1" display with LED backlight, CHIRP Down Imaging and CHIRP 2D sonar. Includes GPS chartplotting with built-in Bluetooth, Ethernet networking capabilities, AutoChart Live with depth, vegetation and bottom hardness mapping, and unit cover.
*Optional 50 kHz transducers available for extreme deepwater use and to obtain 1000 watts.
We have you surrounded. 360 Imaging allows you to isolate your sweep, see 5 preset views or see all around you.
Reach a new low. Find Fish and habitat other sounders can't touch. 50kHz goes deep and wide and 200 kHz delivers high-accuracy returns of baitfish and gamefish.
DOWN IMAGING SONAR
Get a fish-eye's view of what's happening below your boat. Incredible images are created with High-frequency sound waves.
Take command of how your sonar returns appear with our Clear and Max Modes.
DUALBEAM PLUS SONAR
Two beams combine for great detail and a wide coverage area. Use the narrow beam for high-accuracy returns and bottom. Use the wide beam when you want a larger search area.
GPS antenna built into the head unit.
Access software updates to enhance the performance of your Humminbird unit through our My Humminbird section of the site.
DUAL CARD SLOTS
Use one slot for advanced cartography and the other to save screenshots, sonar recordings and waypoints.
HIGH DEFINITION DISPLAY
Provides bright, crystal-clear images for easy viewing in harsh sunlight.
Contour XD is our built-in base map cartography that covers 3,000 US lakes with depth contours and many other locations without contours.
Rig up the ultimate fishing system. Use our 5-Port Ethernet switch to link together multiple Humminbird head units or share transducers.
In darkness and fog, busy channels and treacherous weather, situational awareness is the name of the game.
Battle fish - not other boats. Humminbird's state of the art AIS technology takes the risk and guesswork out of navigating high-traffic channels or low-visibility seas.
Never deviate from your route with the precise control and proven performance of your Humminbird Autopilot System.
Boat performance, weather or water conditions, make sense of it all with our networking solutions.
i-Pilot Link is an integrated GPS Trolling System available on select Minn Kota Ulterra, Terrova and PowerDrive V2 motors which enable your motor and Humminbird to communicate.
Make a map where there is no map. Our patent pending AutoChart Live allows you to create digital, detailed maps live and on the water. You can also use it to enhance your existing charts.
Get an at-a-glance view of fuel consumption, engine performance and other vessel data.
Take wireless control of your Humminbird with our new Bluetooth Remote and Dongle*. *Dongle not required on all models.
CHIRP DOWN IMAGING
|Display Size - Diagonal||12.1"|
|Display Pixel Matrix||1280H x 800V|
|Display Type||Colour TFT|
|Display Colors Grayscale||65,000 Colours|
|Sonar Standard||CHIRP Down Imaging/CHIRP Digital Sonar, DualBeam PLUS|
|Standard Sonar Coverage||16°, 28°, 45° & 75° @ -10db|
|Standard Sonar Frequency||200/455/800 kHz|
|Sonar Optional||50kHz, 83kHz & 50/Low Airmar CHIRP|
|Power Output RMS||1000 Watts*|
|Power Output Peak to Peak||8000 Watts*|
|Depth Capability||350 ft (DI), 600 ft, 3500 ft*|
|Speed||GPS Speed Included|
|Unit Size - Gimbal Mount||14.86"W x 8.90"H x 4.11"D|
|Mount A Type||Gimbal Mount|
|Unit Size - Indash Mount||14.86"W x 8.52"H x 3.90"D|
|Mounting Options||Optional In-Dash Mounting Kit|
|Transducer Standard||XNT 9 DI T|
|Power Input||10.8-20 VDC|
|Power Draw||3.0 Amps|
|Waypoints, Routes, Tracks/Points||2,500, 47, 50/20,000|
|C-Map 4D||Not Supported|
|5 Port Expansion Module||Optional|
|Heading Sensor GPS||Optional|
|External GPS Receiver||Optional|
|AS Interlink||Not Supported|
|Screen Snap Shot||Included|
|Screen Snap Shot||Included|
|Upgradable Internal Software||Included|
|Split Screen Zoom||Included|
|Split Screen Bottom Lock||Included|
|3D Chart View||Included|
|Large Digits View||Included|
|Wide/Narrow Cone Split Screen||Included|
|Custom View Selections||Included|
|Custom Digital Readout||Included|
|View Preset Keys||Included|
|Temperature AlarmFreeze Frame||Included|
|Instant Image Update||Included|
|Mark Structure on Sonar||Included|
|Selective Fish ID+||Included|
|Real Time Sonar||Included|
|X-Press Menu System||Included|
|Card Reader Available||Yes|
|# Card Slots||2|
